High strength, high effciency, safe and reliable, stable performance, corrosion resistance, low discharge and strong endurance
Good quality nylon thickened soild wheels are suitable in both cement hard ground and painted floor, strong and wearable, and stronger bearing capacity.
Parking brake by foot brake operation, the brake apply directly on the caster.
Good quality nylon thickened soild wheels are suitable in both cement hard ground and painted floor, strong and wearable, and stronger bearing capacity.
Parking brake by foot brake operation, the brake apply directly on the caster.
Model |
DT-BHS1016 |
DT-BHS1030 |
DT-BHS1035 |
DT-BHS1530 |
|||||
Capacity |
kg |
1000 |
1500 |
||||||
Minimum Fork Height |
mm |
85/90 |
|||||||
Max. Fork Height |
mm |
1600 |
3000 |
3500 |
3000 |
||||
Load Center |
mm |
450-550 |
|||||||
Stearing Wheel |
mm |
180 x 50 |
|||||||
Load Roller |
mm |
80 x 70 |
|||||||
Fork Length |
mm |
900/1100 |
|||||||
Fork Width |
mm |
150-160 |
|||||||
Mast Height |
mm |
2050 |
2150 |
2350 |
2150 |
||||
Fork Span (Adjustbale) |
mm |
570/Adjustbale |
|||||||
Turning Radius |
mm |
1280/1350 |
|||||||
Lifting Speed (unloden/laden) |
mm/s |
90/140 |
|||||||
Lowering speed (Unloden/Laden) |
mm/s |
120/100 |
|||||||
Lift Motor |
kw |
1.5 |
|||||||
Battery |
v/Ah |
12V/135A |
|||||||
Lift Motor |
kw |
1.5 |
|||||||
Weight |
kg |
310 |
365 |
380 |
415 |
-
Capacity : 1500Kg-2000Kg
-
Capacity : 1500Kg
-
Capacity : 1000Kg-2000Kg
